ACX-3.2 All-Weather Equalizer & Crossover with Paging Mic

$529.00

AudioControl’s ACX All-Weather Amplifiers are rated IPX6 waterproof to withstand the harsh outdoor elements. They deliver honest power levels to the sound system in your boat, UTV, motorcycle, and more.

The ACX-3.2 all-weather sound processor is a high-output pre-amp, for all systems on-road, off-road, or off-shore. The ACX-3.2 can serve as the main control unit in your audio system allowing you to control the output to all of your amplifiers. It features a 4-band graphic equalizer that can be used to tweak your system, depending upon your mood or music selection. The built-in crossover gives you the ability to separate high and low frequencies, and send them to the appropriate amplifier and speakers, maximizing the performance of your system. Adding an ACX-3.2 to your system gives you the assurance that your system can play longer, louder, and cleaner with less distortion.

The low-profile ACX-3.2 takes your experience to another level by combining all of its audio features with a PA microphone!
If you are out on your boat ACX-3.2 allows you to play music and communicate with the person wakeboarding or tubing behind you. Own a food truck? This is great for playing music inside for the cooks, outside for the patrons, and allowing you the ability to call out an order number for a waiting customer.

The ACX-3.2 is a game changer, by offering a quality real-world solution for all of those unique installation needs. This multi-functional piece is part of our all-weather line-up making it the perfect solution for any adventure.

FEATURES

  • 4-Band Stereo Graphic EQ
  • Parabass® Low-Frequency Contouring
  • Variable 24 Db/Octave Linkwitz-Riley Crossover
  • Front, Rear, and Subwoofer Outputs
  • Master Volume, Fader, and Sub-Level Control
  • Parabass® Bass Control
  • High-Gain Input Stage
  • Line Driver: 13-Volts Peak Output
  • Dash or Console-Mountable
  • Included Paging Microphone
  • Selectable Illumination (red or blue)

SPECIFICATIONS

INPUTS

  • Preamp Inputs: 1 (2 channels)
  • Input Gain: 0-20 dB
  • Input Impedance: 20 kΩ

OUTPUTS

  • Preamp Outputs: 6
  • Maximum Output Level: 7.5 Vrms / 9.5 V Peak
  • Output Impedance: 150 Ω

PERFORMANCE

  • Frequency Response: 20Hz-20kHz ±.01dB
  • Total Harmonic Distortion: 0.03%
  • Signal to Noise: 123 dB (inputs set to Balanced)
  • EQ Frequencies: 40 Hz – 80 Hz (parametric), 125 Hz, 1.25 kHz, 10 kHz
  • EQ Cut/Boost: ±10 dB
  • Crossover type: 24 dB/octave Linkwitz-Riley
  • Factory Crossover Setting: 100 Hz
  • Microphone Frequency Response: 100 Hz – 6 kHz
  • Microphone Maximum SPL: 123 dB

CONTROL

  • Remote In

GENERAL

  • Power Supply: High Headroom PWM Switching
  • Current Draw: 300mA
  • Recommended Fuse Rating: 1A

WEIGHT & DIMENSIONS

  • Dimensions: 6.75”W x 5”D x 1”H
  • Weight: 1.6lbs

IN THE BOX: ACX-3.2, Paging Mic, Mounting Brackets, Power Connector, Manual, Warranty

ACX-3.2 All-Weather Equalizer & Crossover with Paging Mic
ACX-3.2 All-Weather Equalizer & Crossover with Paging Mic
ACX-3.2 All-Weather Equalizer & Crossover with Paging Mic
ACX-3.2 All-Weather Equalizer & Crossover with Paging Mic
ACX-3.2 All-Weather Equalizer & Crossover with Paging Mic

Shipping

In stock

Est. arrival October 05

Key features

Customize with the 3-Band Graphic EQ

Adjust bass, midrange, and treble frequencies to make your music sound right.

Boost your bass with the Para-Bass equalizer

Fine-tune the low-frequency output for deep, powerful bass.

Precise Control

Experience smooth transitions between high and low frequencies with the built-in Crossover.

Stay in Control

Adjust the volume of your entire system with the ACX-3.2's volume knob, Subwoofer Level Control, and Fader Knob.

Achieve Optimal Audio Quality

Set the input signal level with the Level dial and know when it's maximized with the LED indicator.

Stay Connected

Communicate easily through your car's audio system with the hand-held Push-to-Talk microphone.

Make Easy Connections

Keep your power, ground, remote, and illumination connections organized with the removable terminal block.

Customize your Microphone Audio

Route your microphone signals to either Rear Outputs or Front and Rear Outputs.

Installation

Get help with your install

Leave the installation to an authorized AudioControl expert.

Find installers near you

More info

1 year manufacturer warranty

Please contact us to request a return. We deal with return requests on a case by case basis after we have had a chance to troubleshoot the issue. If we are unable to resolve your issue over the phone, you will be given an RA (Return Authorization) number. The RA number will need to be written clearly on the outside of the box you are shipping the product in. Product sent back to AudioControl without an RA number will be refused. Please ensure that the RA number is clearly indicated on the outside of the box so we can efficiently process the authorized return.

About this product

ACX all weather EQ is built tough .

Dimensions

Width 6.75”
Height 1”
Depth 5”
Weight 1.6 lbs

User guide

Our products are built for easy installation. As long as your vehicle is compatible, you'll have everything you need to get started, right there in the box.

Download user guide

Find an installer

Let us hook you up with your local AudioControl installation expert. Just enter your location to see approved installers in your neighborhood.
